Chain Link Fence Comparison Chart & Frequently Asked Questions

Chain Link Fence is an excellent option for both domestic boundary fencing and commercial fencing. As Chain Link Fencing is a woven product, this provides the flexibility to install continuous fencing runs of any length by weaving the mesh together allowing you to secure both small and large boundaries.

It is essential to install Chain Link Fencing correctly, however this is something that can be done either by private DIY-ers or by professional contractors with the assistance of our easy-to-follow guide on How to Install Chain Link. Here at Mesh Direct, we offer a complete Chain Link Fence and Post System available in convenient Chain Link Kits, or our friendly and experience team is available to provide bespoke quotations for any boundary. For more information see our guide on Why You Should Choose our Chain-Link Fence System.

Also see below our useful comparison table showing the different types of Chain Link Fence and Post options, plus our Chain Link Fencing Frequently Asked Questions.

Chain Link Fence Component	Key Features
Standard-weight Chain Link F ence	Ideal choice for domestic boundary fence. European made by ISO Certified manufacturer. Green PVC coating to RAL 6005. 1.7mm thick steel core wire underneath PVC coating, overall wire thickness with coating is 2.5mm. Core wire under coating galvanized for high rust resistance. Line wire is included in the price of the Chain Link roll, this is located under the packaging on one end of the roll.
Heavy-duty Chain Link Fence	Stronger option for commercial properties or security fencing. Best choice for dog fencing due to thicker wire. European made by ISO Certified manufacturer. Green PVC coating to RAL 6005. Also available in black PVC coated finish. 2.24mm thick steel core wire underneath PVC coating, overall wire thickness with coating is 3.15mm. Core wire under coating galvanized for high rust resistance. Line wire is included in the price of the Chain Link roll, this is located under the packaging on one end of the roll.
Green PVC Coated Chain Link Fence	Most popular option due to attractive green coating (to RAL 6005). Blends in with greenery to make inconspicuous fence. Available in 90cm (3ft), 120cm (4ft), 180cm (6ft), 240cm (8ft) roll heights. Green post system available for 90cm, 120cm and 180cm fence options. Available in both standard-weight and heavy-duty.
Black PVC Coated Chain Link Fence	Ideal if you have existing black finish posts. Other uses include commercial property fencing, security fencing, MMA hexagon cages. Available in 180cm (6ft) roll height. Available in heavy-duty.
Green Coated Posts For Chain Link Fence	Tubular steel post designed to be very strong but light. Green powder coated to RAL 6005 for attractive finish. Fully galvanized underneath green coating for high resistance to corrosion. European made by ISO Certified manufacturer. Designed to be buried and post-creted into the ground, therefore the overall post length is longer than the height of the chain-link roll to allow for part of the post to be buried. Overall post lengths as follows: Post for 1.8m high chain-link = 2.35m overall length; post for 1.2m high chain-link = 1.8m overall length; post for 0.9m high chain-link = 1.55m overall length.
Chain Link Fence Fittings	If you buy our Chain Link Post System, then the relevant fittings are included in the price of the End Posts, Two-way Posts, Corner Posts. You would normally only need to purchase additional fittings if you are installing the Chain Link onto Wooden, Concrete, or Angle Iron Posts. Typical fittings for Chain Link Fencing include winders, stretcher bars, brackets, angle cleats, eye-bolts. We offer Chain Link Fence Fitting Kits for posts if you are not using our post system. You can also see our useful guide for installing chain-link onto wooden, concrete or angle iron posts.
Gates For Chain Link Fence	Gates can either be installed at the end of a straight section of Chain Link Fence, or you can create a gap for your existing or new gate by using two End Posts. To install a gate at the end of a straight section of Chain Link, simply butt a free-standing gate up against the end of the Chain Link run (the run will usually finish with an End Post). To create a gap part way along a run of Chain Link Fence, you will need to stop the Chain Link using an End Post, then install your free-standing gate, and finally use another End Post to re-start the run of Chain Link on the other-side of your gate. We offer a free-standing single pedestrian gate in a green coated finish (to RAL 6005). The gate includes two gate posts which must be buried and post-creted into the ground, a welded wire mesh gate panel, and a key-locking mechanism. Our gates are available for 1.2m and 1.8m high fencing.

Chain Link Fence FAQs

How much does a Chain Link Fence cost?

›

How to install a Chain Link Fence

›

What height should a Chain Link Fence be?

›

Can you install Chain Link Fence on a slope?

›

What type of posts do I need for Chain Link Fencing?

›

Is line wire included with the rolls of Chain Link?

›

How do I shorten rolls of Chain Link Fence?

›

How do I join two rolls of Chain Link Fencing together?

›

How do I repair a hole in Chain Link Fencing?

›

Does Chain Link Fence need a top rail?

›

Can I install Chain Link Fence myself?

›

How many runs of line wire do I need for Chain Link Fencing?

›

Whatever your needs, at Mesh Direct we can provide you with the right wire mesh, from animal enclosures like dog runs, catios and chicken coops, to pest proofing including insect mesh, fox proofing, rodent proofing. If you need any help with your project, don't hesitate to get in touch with our friendly and experienced team.
